DKVM-IP8 User Manual
10 / 104
The factory default settings are:
Username admin
Password admin
The super user has all permissions to administrate your DKVM-IP8:
After login, the system will prompt for changing the default username and password to user
specific settings.
Control servers via Remote Console
The Remote Console is the redirected screen, keyboard and mouse of the remote host
system. The Remote Console will behave exactly the same way as if you were sitting
directly in front of the screen of your remote system. That means that both the keyboard
and mouse can be used in the usual way. Open the console by selecting the preview
picture on the main site of the HTML front end. Figure 1-2 shows the top of the Remote
Console.
