DKVM-IP8 User Manual
12 / 104
2. Introduction
The KVM over IP technology (DKVM-IP8) combines digital remote KVM access via IP
networks with comprehensive and integrated system management. The DKVM-IP8 defines
a new class of remote KVM access devices that can save your money, time, space, and
equipment.
The DKVM-IP8 provides convenient, remote KVM access and control via LAN or Internet. It
captures, digitizes, and compresses video signal and transmits it with keyboard and mouse
signals to and from a remote computer. DKVM-IP8 provides a non-intrusive solution for
remote access and control. Remote access and control software runs on its embedded
processors only but not on mission-critical servers, so that there is no interference with
server operation or impact on network performance.
The DKVM-IP8 supports console of USB style keyboard, mouse, and HDDB15 video
interfaces. The DKVM-IP8 will automatically detect the current video mode of the console,
however manual fine-tuning is recommended to receive the best video quality.
2.1 Feature overview
♦ Manage servers around the world.
♦ KVM (keyboard, video, and mouse) access over IP and analogous telephone line
(modem needed)
♦ Full control under any OS, in BIOS mode, during boot, at Blue Screens
♦ No additional software necessary on servers
♦ Can be used with most standard KVM
♦ 256 bit SSL encryption of all transmitted data and Certificate management
♦ Automatically senses video resolution for best possible screen capture
♦ Serial over LAN, Remote serial power control via web
♦ Video Resolution up to:
Local console 1920 x 1440
Remote console 1600 x 1200, High-color depth 16 bits
♦ High-performance mouse tracking and synchronization
♦ Automatic adjustment of data rate to transmission line
♦ Drive redirection function on the remote console control bar, Remote mass storage
control.
♦ Can be controlled over all java-enabled Browsers
♦ Firmware update via web interface
♦ Port to connect a user console for direct analogous access to KVM switch
