JVC DLA-VS4800 [25/72] Turning on the main power

1 Check to ensure that this projector, computer, and switching hub are properly connected

2 Connect the power cord to the power input terminal of this projector

You can secure the power cord to this projector.

A Attach the plug holder to the power cord.

B Insert the plug holder into the projector until the upper and lower securing levers are locked.

3 Insert plug into the power outlet on the wall

4 Remove the lens cap

5 Turn on the main power of the projector to set to [I]

● The [STANDBY/ON], [LAMP], and [WARNING] indicators light up for about 45 seconds, after which the

[STANDBY/ON] indicator turns red.

NOTE:

● The default IP address of all DLA-VS4800G is “192.168.0.2”. If multiple units of DLA-VS4800G are used on the same

network, do not turn on the main power of more than one projector unit at the same time. Doing so will result in

duplication of the IP address, and thereby preventing proper access.

● When using multiple units of DLA-VS4800G, turn on the main power of the second unit and configure accordingly only

after configuration of the first unit is complete. Configure subsequent units using the same procedure.

● When duplication occurs in the IP address, make sure that only one unit of DLA-VS4800G is connected on the same

network (turn off the main power of the other DLA-VS4800G units). Allow a time interval of at least 10 minutes before

accessing. If access fails, turn off the power of all network equipments on the same network, followed by turning them

on again.

Turning On the Main

Power

CAUTION:

● Do not connect the power cord when a lens (optional)

is not attached.

Power Cord

(Supplied)

Securing Levers (Upper and lower)

AC INLET
