Gnatus TIMEX 70 [40/44] Unforeseen events solution of problems
![Gnatus TIMEX 70 [40/44] Unforeseen events solution of problems](/views2/1462552/page40/bg28.png)
40
Problem Probable cause Solution
- Not functioning pro-
perly.
- Damaged fuse.
- Lack of power.
-Turn the device off and call a tech-
nician.
-Check the wiring
-At radiography appe-
ars a semi circle.
-Wrong positioning of cylin-
der.
-Radiograph using the parallelism
technique, using for that auxiliary
lines of collimator cylinder.
-Radiography totally
dark.
-Excess of XR time;
-Development;
-Developer with inadequate
temperature.
-Developer with inadequate
mixture.
- Check if the time is well adjusted
according to radiographic techni-
ques table;
-Check the development time.
-AThe quicker is the developer
action the bigger is the solution
temperature.
-Prepare the mixture again.
NOTE: Kodak developer does not
use mixture.
-Radiography with a
dark targe.
-Development Camera with
light penetration.
-Avoid light output.
Message in the Display
-A1
-A2
-A3/A5
-A4
-Sb
-Invalid Voltage:
Voltage higher than the
equipment’s limit.
-Invalid Voltage:
Voltage lower than the
equipment’s limit.
-Fault in electrical network
-Exposure error:
Shutter button released be-
fore time.
-Protection against excessi-
ve tube heating.
-Check the supply voltage
-See about overpotential protection
on page 12.
-Check the supply voltage
-See about overpotential protection
on page 12.
-Turn on the equipment. In case of
failure lasts, request a technician
service.
-Turn on the equipment.
-Wait for the correct cooling time to
reestablish the normal functions –
see page 12 – cooling item.
Upon coming across any problem in operation, follow the instructions below to
check and repair the problem, and/or get in touch with your representative.
UNFORESEEN EVENTS – SOLUTION OF PROBLEMS
