Gnatus TIMEX 70 [9/44] Technical specifications
![Gnatus TIMEX 70 [9/44] Technical specifications](/views2/1462552/page9/bg9.png)
9
TECHNICAL SPECIFICATIONS
General
Technical features
Model
• Timex 70 E X-Ray Mobile Column
• Timex 70 E X-Ray Wall
• Timex 70 E X-Ray Pantographic Mobile Column
• Timex 70 E X-Ray Pantographic Wall
• Timex 70 E X-Ray Pantographic Fixed Column
Classification of Equipment as per ANVISA:
Class III
Classification of Equipment as per standard IEC 60601-1:
Protection against Electric Shock - Type B and Class I Equipment (IEC 60601-1)
Degree of safety of application in presence:
Equipment not suited to an anesthetic mixture inflammable with air, oxygen or nitrous
oxide.
Mode of Operation
Continuous operation with intermittent load
Protection against Dangerous Ingress of water
Common device (Equip. Closed without protection against ingress o water)
Generator
Immersed in Oil
Transformer Oil
Lubrax Industrial AV-58-BR-Petrobras
Cylindrical Collimator
Totally armored
Tube Model
The model/tube type and its serial number are in the product’s certificate
Target Material
Tungsten
Reference Axis
19o in relation to anode
Target Angle
19o
