Satelec Acteon Group X-Mind DC 80 [6/65] X ray system
![Satelec Acteon Group X-Mind DC 80 [6/65] X ray system](/views2/1462556/page6/bg6.png)
X
X
-
-
M
M
i
i
n
n
d
d
®
®
D
D
C
C
5
5
The “X-Mind
DC” X-ray system (Fig. 1) consists of:
TUBEHEAD
SPACER CONE
PANTOGRAPH-TYPE ARM
TIMER
WALL PLATE
BRACKET
OPTIONAL
− long 12” (31 cm) cone
− short 8” (20 cm) cone
− long cone 12” (31 cm) with a rectangular section sized 44x35mm
− second “CONTROL BUTTON” with extension cable
− RX signaling lamp for external use: X-Mind
LIGHT
− remote control button: X-Mind ECB
Fig. 1
1. “X-Mind
DC” X-RAY SYSTEM
