Hyundai H-LCD3200 [14/39] Turning on off the tv

Other Operations

Turning on/off the TV

Turning on

1. Connect the power input port on TV with AC power cable, and then connect it with A power supply,

turn on the AC switch of the TV, the indicator turns red, TV enters into standby mode.

2. In standby mode, press POWER button on TV or on the RC to turn on the TV, the indicator flashes and

turns red, green by turns when starting the TV, the LCD TV starts to work after the indicator turn to be

green.

Turning off

1. When the temporary turning off is required, please press POWER button on TV or on the RC.

2. When a complete turning off is required, please turn off the AC switch on the TV and unplug the power

cable from the power socket.

Note: If there is an accident power off, the TV will be in standby mode automatically after re-supply the

power. To ensure the normal use of the TV, the frequent turning on and off is forbidden, when there is an

accident power off, it is recommended to unplug the power cable from the power socket.

Automatic turning off for no TV signal input

When the TV working in RF receiving mode, the TV will enter standby mode automatically 5 minutes after

there is no any signal (such as the programs are stopped by TV station)

Standby Mode

Press POWER button on TV or on the RC, the LCD TV will store the current settings and enter into standby

mode, press POWER button on TV or on the RC again, the TV will be back to the normal working mode.

If the TV is restarted after the TV entering into the standby mode or after shutting off the power, the TV will

work with the setting signal source mode, which was set before turning off.

Switching the Signal Source

Press TV/AV button on the TV or AV button on the RC to enter the menu, ad then select the signal sources

among TV, AV1, AV2, AV3, SVIDEO, COMP1, COMP2, PC and HDMI, HDMI2, by pressing CH+/CH-

buttons on the TV or P+/P- buttons on the RC.

Channel Selection

Press CH+/CH- buttons on the TV or P+/P- buttons on the RC to increase or decrease the channel numbers,

if the next channel is set as “Skip on”, the system will select the channel after this channel. Also, the channel

can be selected by pressing the number buttons. The channel number of the selected channel will display on

the screen as green for 6 seconds since it is selected, and then, it will disappear.

When you are inputting the channel number through number button, you can press OK button to switch to

the channel corresponding to the current number without finishing all these 3 numbers, if the input is not

correct, please press MENU button to cancel.

Additionally, when TV is in AV, SVIDEO, COMP, PC or HDMI mode, the TV will work in TV mode and

play the corresponding channel if any number button is pressed.

Adjusting Volume

When there is no any menu displaying on the screen, the volume can be adjusted continuously by pressing

VOL+/VOL- buttons on the TV or by pressing V+/V- buttons on the RC, the range can be adjusted is 0-100,

the volume indication band will be disappeared 2 seconds after adjusting the volume.

Mute and Relevant Functions

By pressing MUTE button on the RC, the sound on/off mode can be selected. The MUTE mode indication

information will remain on the lower left position as the following picture. The mute mode can be released if
