Appendix
Appendix
12
Engb
Specifications
General
Rated power source ........... 14.4 V DC
(allowable voltage range:
12.0 V to 14.4 V DC)
Earthing system .................Negative type
Maximum current consumption
  ................................ 10.0 A
Dimensions (W × H × D):
DIN
Chassis ........................188 mm × 118 mm × 170 mm
Nose ...........................171 mm × 97 mm × 14 mm
D
Chassis ........................178 mm × 100 mm × 168 mm
Nose ...........................171 mm × 97 mm × 16 mm
Weight ...............................1.9 kg
Display
Screen size/aspect ratio ..... 7 inch wide/16:9
(effective display area:
156.6 mm × 81.6 mm)
Pixels ...................................384 000 (800 × 480)
Display method ..................TFT Active matrix driving
Backlight ............................LED
Colour system .....................PAL/NTSC compatible
Tolerable temperature range:
Power on ..................... −10 °C to +60 °C
Power off .................... −20 °C to +80 °C
Audio
Maximum power output .... 50 W × 4
50 W × 2 ch/4 Ω + 70 W ×
1
ch/2 Ω (for subwoofer)
Continuous power
output ................................. 22 W × 4 (50 Hz to 15 kHz,
5 %THD, 4 Ω LOAD, Both
Channels Driven)
Load impedance ................ 4
Ω (4 Ω to 8 Ω [2 Ω for 1 ch]
allowable)
Preout output level (max) .... 2.2 V
Preout impedance .............1 k
Ω
Equaliser (5-Band Graphic Equaliser):
Frequency ................... 100 Hz/315 Hz/1.25 kHz/
3.15 kHz/8 kHz
Gain.............................±12 dB
Loudness contour:
Low ......................3.5 dB (100 Hz), 3 dB (10 kHz)
Mid ...................... 10 dB (100 Hz), 6.5 dB (10 kHz)
High ..................... 11 dB (100 Hz), 11 dB (10 kHz)
(Volume: −30 dB)
HPF:
Frequency ................... 50 Hz/63 Hz/80 Hz/
100 Hz/125 Hz
Slope ........................... −12 dB/oct
Subwoofer:
Frequency ................... 50 Hz/63 Hz/80 Hz/
100 Hz/125 Hz
Slope ........................... −18 dB/oct
Gain.............................−24/+6 dB
Phase ..........................Normal/Reverse
Bass boost:
Gain.............................0 dB to +12 dB
Bluetooth
Version ...............................Bluetooth 2.1+EDR
Output power ..................... + 4 dBm Max. (Power class 2)
FM tuner
Frequency range ................87.5 MHz to 108.0 MHz
Usable sensitivity ................ 9 dBf (0.8 μV/75
Ω, mono,
S/N: 30 dB)
Signal-to-noise ratio ...........72 dB (IEC-A network)
Distortion............................ 0.3 % (at 65 dBf, 1 kHz, stereo)
0.1 % (at 65 dBf, 1 kHz, mono)
Frequency response ........... 30 Hz to 15 000 Hz (±3 dB)
Stereo separation ...............45 dB (at 65 dBf, 1 kHz)
MW tuner
Frequency range ................531 kHz to 1 602 kHz (9 kHz)
Usable sensitivity ................25 μV (S/N: 20 dB)
Signal-to-noise ratio ...........62 dB (IEC-A network)
LW tuner
Frequency range ................153 kHz to 281 kHz (1 kHz)
Usable sensitivity ................28 μV (S/N: 20 dB)
Signal-to-noise ratio ...........62 dB (IEC-A network)
GPS
GPS receiver:
System ........................ L1, C/Acode GPS
SPS (Standard Positioning
Service)
Reception system ....... 32-channel Multi-channel
reception system
Reception frequency ...1 575.42 MHz
Sensitivity....................−142 dBm (typ)
Frequency ...................Approx. once a second
GPS aerial:
Aerial ......................... Micro strip flat aerial/right-
handed helical polarisation
Aerial cable .................3.55 m
Dimensions (W × H × D)
.................................. 33 mm × 14.7 mm × 36 mm
Weight ........................73.7 g
Note
Specifications and design are subject to possible
modifications without notice due to improve-
ments.
