Domestic
Commercial Products
40RUA – 50Hz
18.3 TO 59.2 kW
DIRECT EXPANSION
PACKAGED AIR-HANDLING UNITS
Carrier Corporation • Syracuse, N.Y. 13221 F.O.B. SHIPPING POINT
SUBJECT TO CHANGE WITHOUT NOTICE TYPE OF SALE: 13SS (40RUA 07-16 SIZES) FREIGHT AS PER D.O.M.
UNIT SHIPPING POINT: Monterrey, MX 13SB (40RUA 25 SIZE)
MFG. POINT: Monterrey, MX
PAGE
1
40RUA 18.3 TO 29.1 kW CHASSIS SHOWN
40RUA DIRECT EXPANSION
PACKAGED AIR-HANDLING UNITS
STANDARD FEATURES
1. PURON (R-410A) HFC Refrigerant
2. Cleanable insulation treated with an anti-microbial
agent.
3. Two sloped condensate pans on each unit for
horizontal or vertical applications.
4. 2 inch filters.
5. Powerful belt-driven forward curved fans.
6. Factory-installed fan motor and contactor.
7. Refrigerant metering devices (TXV's) -- factory
installed.
8. Easy maintenance -- removal of a single panel
allows access to virtually all components.
9. Single refrigerant circuit on 07 and 08 models, dual
refrigerant circuit on 12-25 models. Dual circuit
models can be field modified for use on single
circuit condensing units.
10. Single blower on 07 to 12 sizes; dual blower on
14 to 25 sizes.
11. 24-volt terminal block for control wiring connection.
40RUA DIRECT EXPANSION
PACKAGED AIR-HANDLING UNITS
The 40RUA units are completely packaged direct
expansion air-handling units offering the ultimate in
installation ease and flexibility. Combined with Carrier
38AUZ/D Series condensing units these packaged air
handling units offer system capacities from 18.3 to
59.2 kW. These units may be installed in either the
vertical or horizontal configuration with no
modifications. Powerful fan systems allow easy
adaptation to existing ductwork. Heating capability is
provided by electric heaters, hot water coils or steam
coils.
Certified to ISO 9001:2000
