Domestic
Commercial Products
40RUA – 50Hz
18.3 TO 59.2 kW
DIRECT EXPANSION
PACKAGED AIR-HANDLING UNITS
Carrier Corporation • Syracuse, N.Y. 13221 F.O.B. SHIPPING POINT
SUBJECT TO CHANGE WITHOUT NOTICE FREIGHT AS PER D.O.M.
PAGE
6
FIELD-INSTALLED ACCESSORIES (cont)
40RUA (07-12) ACCESSORIES
ORDERING
MODEL NUMBER
DESCRIPTION
APPROX.
SHIPPING
WT. kg. (lbs)
CAPLENUM001A00 †
CAPLENUM004A00 †
† Discharge plenums are shipped knocked down and require field assembly. Cannot be used with electric heat or horizontal
application.
40RUA (14-25) ACCESSORIES
ORDERING
MODEL NUMBER
DESCRIPTION
APPROX.
SHIPPING
WT. kg. (lbs)
CAPLENUM002A00 †
CAPLENUM005A00 †
† Discharge plenums are shipped knocked down and require field assembly. Cannot be used with electric heat, or horizontal
applications.
NOTE: Accessories are unpainted unless noted otherwise in the description.
CAECOMZR001A00 Economizer - Enthalpy Controlled 84 (185)
CAHWCOIL001A00 Hot Water Coil (2 row) 88 (195)
Discharge Plenum 61 (134)
Discharge Plenum - Painted 61 (134)
CARAGRIL001A00 Return Air Grille 12 (27)
CARAGRIL004A00 Return Air Grille - Painted 61 (134)
CASTCOIL001A00 Steam Coil (1 row) 98 (215)
CASUBASE001A00 Floor Mount Base (Subbase) 6 (14)
CASUBASE003A00 Floor Mount Base (Subbase) - Painted 6 (14)
CAOVRFLW001A00 Condensate Overflow Switch Assembly N/A
CASUSPEN001A00 Overhead Suspension Brackets 1 (1.5)
CASTCOIL002A00 Steam Coil (1 row) 154 (340)
CARAGRIL005A00 Return Air Grille - Painted 23 (51)
CARAGRIL002A00 Return Air Grille 23 (51)
Discharge Plenum - Painted 113 (250)
Discharge Plenum 113 (250)
CAHWCOIL002A00 Hot Water Coil (2 row) 129 (285)
CAECOMZR002A00 Economizer - Enthalpy Controlled 154 (340)
CASUBASE001A00 Floor Mount Base (Subbase) 6 (14)
CASUBASE003A00 Floor Mount Base (Subbase) - Painted 6 (14)
CAOVRFLW001A00 Condensate Overflow Switch Assembly N/A
CASUSPEN001A00 Overhead Suspension Brackets 1 (1.5)
