MEASUREMENT FOUNDATION

ZHM 125B

Application

Remove the cap from the top side and place on the bottom side.

The instrument switches on automatically.

Press the measuring electrodes as far as possible into the material.

Always measure the moisture in the wood perpendicular to the bre structure.

Repeated measuring yields representative measured data.

Once the measurement is nished, reattach the cap on the top side and the instrument switches itself off.

Display

The reading is shown in the form of bars:

a continuous line

even values e.g. 6, 8, 14

dotted line

uneven values e.g. 7,11

Overow: reading >44% / 2.0%

Please note: Characteristics due to growth or type of wood and deviating wood temperatures may make it necessary

to correct the displayed values. Measurements should be carried out according to the drying and weighing/calcium

carbide method in the case of inspections or for reference purposes.

•
