Wisenet SNO-7084RP [110/180] Setup screen

802.1x

When connecting network, you can choose whether using 802.1x protocol, and then install

the certification.

1. From the Setup menu, select the

<Network (

)> tab.

2. Click <802.1x>.

3. Set the <IEEE 802.1x setting>.

• IEEE 802.1x : Specify the use of the

802.1x protocol.

• EAP type : Select EAP-TLS or LEAP.

• EAPOL version : Select version 1 or 2.

• ID : Enter the client certificate ID in

EAP-TLS and the user ID in LEAP.

• Password : Enter the client private

key password in EAP-TLS and the user password in LEAP. You do not have to

enter the password in EAP-TLS if it uses a key file that is not encrypted.

If the connected network device does not support the 802.1x protocol, the protocol will not

operate properly even if you set it.

LEAP is an authentication method with poor security. Use it only in an environment where EAP-

TLS is not available.

4. Install/remove the certificate.

The certificate is needed only for EAP-TLS.

• CA certificates : Select a public certificate that contains the public key.

• Client certificate : Select a public certificate that contains the client certificate key.

• Client private Key : Select a public certificate that contains the client private key.

5. When done, click [Apply (

)].

To install/remove 802.1x related certificates

1. Press the [Browse ( )] button for each item and select a certificate to install.

2. If no certificate is installed, you will see “Not Available” appearing next to the selected

item.

3. Press the [Install (

)] button to start installation with a message of “Installed”

next to the item.

4. Press the [Delete (

)] button to remove the certificate.
