Replacing the Front Panel
1. Make sure the inner cover is closed.
Warning Tone
If the front panel is not detached within 5 seconds after the ignition is turned off, a warning
tone will sound.
Note:
• You can cancel the Warning Tone function. (Refer to page 19.)
2. Replace the front panel by
clipping it into place.
12
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
13
1/CRB1643/Eng/1~52 09-05-2001 08:22 Page 13
