Product Usage

1.Network

Before you can normally use wireless PIR detector, you must set network settings.

Two ways to set:

 Via wireless alarm programming keyboard

Under this mode, you enable matching mode at keyboard, and power up the detector. When

power indicator is ON, dial vandal-proof switch and indicator is flashing. Wait about 10s, if

the indicator is OFF, the matching is successful. If the indicator flashes for three times, the

matching is failed. You shall follow these steps and try again.

 Via setting MAC address

Under this mode, you set detector MAC to the MAC address list of wireless alarm host via

keyboard and power up the detector. Wait about 40s, if indicator is OFF, the matching is

successful.

Note:

If the detector has been matched to other alarm host, you cancel previous matching by quickly

dialing vandal-proof switch. (5 times within 1s)

2.LED Setup

You can set LED plunger pin to control LED indicator, while the ON/OFF of indicator represent

certain instructions.

You can set two plans at the plunger pin:1&2 and 2&3， select 1&2 as LED OFF，select 2&3

as LED ON, default setup is LED ON.

Note:

This operation does not influence normal operation of detector.

3.Pulse Count Setup

You can set P.COUNT plunger pin (as pulse count plunger pin) according to product usage

environment or distance requirement for sensor.

You can set two levels for position of plunger pin: 1&2 and 2&3; select 1&2 (IP) as level 1 pulse;

select 2&3 (2P) as level 2 pulse. Default setup is 1P. 1P sensor sensitivity is high while 2P sensor

sensitivity is low.

4.Installation Test

You can test working status of detector:

Within detection range of the detector, walk at the rate of 1m/s to test, red indicator keeps ON

for 2s, which means infrared is triggered, and detector enters alarm status. It outputs alarm

signal, and red indicator is ON.
