Tp-Link TD-W8968 V4 [2/2] Configuring the modem router

Tp-Link TD-W8968 V4 [2/2] Configuring the modem router

Quick Setup - WAN Configurations

OtherCountry:

ISP: Other

WAN Link Type:

PPPoE (PPP over Ethernet)

35VPI/VCI: 8 ([0~255] / [32~65535])

XXXXXXXXXXX

PPP Username:

*************

PPP Password:

Encapsulation Mode:

LLC/SNAP-BRIDGING

(optional)

1480

MTU (bytes):

(optional)

PPPoE Service Name:

(optional)

Back Skip WAN

Next

/

Quick Setup - Wireless Configurations

TP-LINK_XXXXWireless Network Name :

Network Authentication:

WPA2-Personal (best/recommended)

Wireless Network Key : ********

Enable Wireless:

Back Skip Wi-Fi

Next

(Also called SSID)

http://tplinkmodem.net

Login

admin

admin

Quick Setup - Operation mode

Skip WAN

Next

Choose Operation mode:

Wireless Router Mode

3G Router Mode

ADSL Modem Router Mode

Enable IPv6 for this service

Enable 3G as a backup access

©2016 TP-LINK

Configuring the Modem Router

Wireless

Connect wirelessly by using the SSID

(wireless network name) and Wireless

Password printed on the product label at

the bottom of the modem router.

1. Connecting your computer to the modem router (Wired

or Wireless).

Wired

2. Configuring the modem router via a web browser.

Note: All the Internet settings in the figure below are used for demonstration only.

D Verify or change the Wireless settings (wireless network settings) and click

Next to continue.

E Check all the parameters and click Confirm to complete the configuration.

Note: You may personalize your wireless network name and key. Once done, you will have to reconnect to

your Wi-Fi network using the new wireless network name and key.

Note: If the login window does not appear, please refer to FAQ > Q1.

B Click Next to run the Quick Setup, and select the Operation mode. Here we

use ADSL Modem Router Mode as an example. Then click Next.

Ethernet cable

Please consult your ISP (Internet Service Provider) for the following information

before configuring the modem router.

VPI and VCI: _______ WAN Link Type: _______

Encapsulation Mode (optional): _____________

If your WAN Link Type is PPPoE/PPPoA, please get further information of your

account username and password.

Connect a computer to the modem router and the LAN LED lights up.

USB Features

Use the USB port for media sharing, storage sharing and printer sharing across your

local network. You can also set up an FTP server to access your files remotely

through the Internet.

ADSL LAN4/WAN LAN3 LAN2 LAN1 USB WiFi WPS ON/OFF POWER

RESET

The USB port can also be used for 3G Modem Sharing. Insert the 3G USB modem into

the USB port, and share your 3G Internet with multiple devices or use the 3G network

as a backup solution for Internet access.

Remote

Access via FTP

Server

Printer Sharing

Local Storage

Sharing

Media Sharing

To learn more about the USB features,

visit http://tp-link.com/app/usb or simply scan the QR code.

USB Sharing Ports

Wireless

Wired

A Enter http://tplinkmodem.net or 192.168.1.1 in the address bar of a web

browser. Use admin for both username and password, and then click Login.

Ethernet cable

ADSL

LAN4/WAN LAN3 LAN2 LAN1 USB WiFi WPS ON/OFF POWER

RESET

C Select your Country and ISP from the drop-down list. Complete the WAN

settings with the information provided by your ISP and click Next. Here we

use PPPoE for demonstration.

FAQ (Frequently Asked Questions)

Q1. What can I do if the login page does not appear?

A1. Make sure the computer is connected to the modem router properly.

A2. If the computer is set to a static or xed IP address, change it to obtain an IP address

automatically from the modem router.

A3. Verify http://tplinkmodem.net is correctly entered in the web browser and press Enter.

A4. Use another web browser and try again.

A5. Reboot your modem router and try again.

A6. Disable and enable the active network adapter.

Q2. What can I do if I cannot access the Internet?

A1. Make sure the telephone and Ethernet cables are plugged in correctly.

A2. Try to log into the web management page of the modem router using the default

address at http://tplinkmodem.net. If you can, try the following answers. If you cannot,

change your computer to obtain an IP address automatically from the modem router.

A3. Consult your ISP and make sure all the VPI/VCI, WAN Link Type, account username and

password are correct. If they are not, please replace them with the correct settings and

try again.

A4. Restore the modem router to its factory default settings and recongure the modem

router by following the instructions in this Quick Installation Guide.

A5. Please contact our Technical Support if the problem still exists.

Q3. How do I restore the modem router to its factory default

settings?

A1. With the modem router powered on, press and

hold down the Reset button on the rear panel of

the modem router for more than 5 seconds and

then release it. If all LEDs turn on momentarily,

you restore the modem router successfully.

A2. Log into the web management page of the modem router, and go to Management >

Settings > Restore Default, click Restore Default Settings and wait until the reset

process is complete.

Q4. What can I do if I forget my password?

Web Management page password:

Refer to FAQ > Q3 to reset the modem router, and then use admin (all lowercase) for

both username and password to log in.

Wireless Network password:

A1. The default Wireless Password/PIN is printed on the product label of the modem router.

A2. If the default wireless password has been changed, log into the modem router's web

management page and go to Wireless > Security to retrieve or reset your wireless

network password.

Q5. What can I do if the ADSL LED does not turn solid on?

A1. Check your cables and make sure they are all plugged in correctly, including the

telephone lines and power adapter.

A2. Manually change your DSL settings. Log into the modem router’s web management

page. Go to Advanced Setup > DSL, untick all the modulation options except G.D mt

Enabled, ADSL 2 Enabled and AnnexL Enabled and click Save/Apply.

A3. Restore your modem router to its factory default settings by referring to FAQ > Q3.

A4. Remove the ADSL splitter, directly connect the modem router to the phone jack and

then reconfigure the modem router by following the instructions in this Quick

Installation Guide.

A5. Contact your Internet service provider to verify if the ADSL line is in good status.

A6. Please contact our Technical Support if the problem still exists.

Reset Button

Press & Hold for more than 5 seconds

ADSL

LAN4/WAN LAN3 LAN2 LAN1 USB WiFi WPS ON/OFF POWER

RESET
