TD-W8961N 300Mbps Wireless N ADSL2+ Modem Router User Guide
3
Chapter 1 Introduction
1.1 Product Overview
TP-LINK’s Modem Router is a combined wired/wireless network connection device with
integrated wireless router and DSL modem, reducing hassle of configuration and saving space.
With ADSL and WAN, the modem router is compatible with ADSL connections and fiber/cable
access.
With Ethernet ports and antennas, the modem router provides wired and wireless access for
multiple computers and mobile devices.
With various features and functions, the modem router is the perfect hub of your home or
business network.
1.2 Product Appearance
1.2.1 The Front Panel
The LEDs locate on the front panel of the modem router. They indicate the device’s working
status. For details, please refer to LED Explanation.
LED Explanation:
Name Status Indication
System initialization comp
letes.
On
System initializing or firmware upgrading is in process. Do not
disconnect or power off the modem router.
Flash
(Power)
Off
Power is off.
On
ADSL synchronization is established.
ADSL synchronization is in progress.
Flash
(ADSL)
ADSL synchronization fails. Please refer to Note 1
for
troubleshooting.
Off
Internet connection is available.
On
There is data being transmitted or received via the
Internet.
Flash
(INTERNET)
Off
No successful Internet connection is available or the modem
router is operating in Bridge mode. Please refer to Note 2
for
troubleshooting.
