Chapter 1
Get to Know About Your Extender
1. 2. 1. LED Explanation
You can check the extender’s working status by following the LED Explanation table.
Name Status Indication
(RE)
Solid blue
The extender is connected to the router, and is in a good
location.
Solid red
The extender is connected to the router, but is too far away
from it.
Blinking WPS connection is in progress.
Off No active connection.
2.4GHz
On
The extender is connected to the 2.4GHz wireless network of
your host router.
Off No 2.4GHz wireless connection.
5GHz
On
The extender is connected to the 5GHz wireless network of
your host router.
Off No 5GHz wireless connection.
Power
On The extender is on.
Blinking The extender is initializing.
Off The extender is off.
1. 2. 2. Port and Button Description
Ports or Buttons Description
WPS Button
Press the WPS button on your host router, and immediately press the WPS
button on the extender. The LED of the extender should change to solid
blue, indicating successful WPS connection.
Power Button Press the Power button to turn on or off the extender.
LED Button Press the LED button to turn on or off all the LEDs.
Reset (Hole)
Use a pin to press and hold the Reset button until all the LEDs turn on
momentarily to reset the extender.
Ethernet Port
Connect your Ethernet-only device to the Ethernet port of the extender to join
the Wi-Fi network.
