Tp-Link RE650 V1 [9/40] 2 method two via a web browser

Chapter 2

Set Up Internet Connection

• For more information about using WPS button on your host router, please refer to the router

manufacturer’s user guide.

2. Wait until the LED changes to solid blue, which indicates that the WPS connection

is successful. If it doesn’t, please refer to Method Two: Via a Web Browser.

3. If you are connecting the extender to a dual-band router but only the 2.4GHz or 5GHz

LED is on, repeat Step 1 and 2 to connect to the other band.

4. Enjoy! Connect to the extended network and enjoy the Internet. Both extended

networks share the same SSIDs (network names) and passwords as those of your

host networks.

Tips:

Since the performance of the extended networks will be affected by the distance between extender

and host router, we recommend that you relocate your extender by referring to Position Your Extender.

2. 1. 2. Method Two: Via a Web Browser

1. Connect your computer to the extender's wireless network.

Tips:

Before connecting, please find the SSID (network name) on the label of the extender.

• For Windows Users

1 ) Unplug the Ethernet cable from your computer (if any).

2 ) Click the Wi-Fi icon on the taskbar and connect to the extender’s wireless

network: TP-LINK_Extender_2.4GHz or TP-LINK_Extender_5GHz.

onnections are available

Wireless Network

onnection

TP-LINK_Extender_2.4GHz

TP-LINK_Extender_5GHz

Connect automatically

Connect

√

• For Mac OS X Users

1 ) Unplug the Ethernet cable from your computer (if any).

2 ) Click the Wi-Fi icon in the top right corner of the screen, and connect to the

extender’s network: TP-LINK_Extender_2.4GHz or TP-LINK_Extender_5GHz.
