Quick Installation Guide
AV500 Powerline Adapter with AC Pass Through
Package Contents
Resource CD
(For Windows Only)
Ethernet Cable
QIG
Warning on Final Location
Powerline Adapter
7106504095 REV1.0.1
* The provided power plug may dier from the picture due to dierent
regional power specications. Here we take the EU version as an example.
*
MODEL NO.
TL-PA4010P
NOTE:
It's strongly recommended that you plug the adapter directly into the
wall socket, for some power strips have surge protector which can lter data.
TL-PA4010P
AV500 Powerline Adapter with AC Pass Through
Pair
LED and Button Descriptions
1
*
Five minutes after the device connected to the adapter is turned o, the adapter will
automatically switch to power-saving mode.
Item Status Description
Power LED
Powerline LED
Ethernet LED
Solid
Solid
Solid
Blinking
Blinking
Blinking
O
O
O
The adapter is on.
The adapter is o.
The adapter is in power-saving mode or in pairing
procedure.
The adapter is connected to a powerline network.
The adapter is transferring data.
The adapter isn’t connected to any powerline network
or is in power-saving mode. *
The Ethernet port is connected, but there is no data
being transferred.
The Ethernet port is transferring data.
The Ethernet port isn’t connected.
Item
Pair Button
Description
Pair button is used to secure a powerline network. To secure
your network, please refer to Appendix: Using the Pair Button.
Pair Button
Power LED
Powerline LED
Ethernet LED
Integrated Electrical Socket
Integrated
Electrical Socket
The integrated electrical socket allows additional devices or
multiple sockets to be connected to the adapter just like to a
normal wall socket. No electrical socket is lost.
Pair
Network Installation
To add another adapter
TP-LINK powerline adapters are Plug and Play. After taking the steps above,
y
ou can surf the Internet
.
Plug an additional adapter into the wall socket, and the connection will be
established automatically within 60 seconds.
NOTE:
1.
2.
To surf the Internet, please make sure that your router is properly
connected to the Internet.
If the adapters fail to automatically link to each other, you can
establish a private network by using the pair button. To set up a
private network, please go to Appendix: Using the Pair Button for
detailed instructions.
2
LINE
1
2
3
4
Power
5
4
1
2
3
Pair
