Launch CRP-229 (301050175) [8/29] Knowledge of crp229

LAUNCH CRP229

User's Manual

2.2 CRP229 Accessory Checklist

Common accessories for each CRP229 are same, but for different

destinations, the accessories of CRP229 (such as diagnostic software,

testing connectors) may vary. Please consult from the local agency or

check the package list supplied with CRP229 together.

Table 2-3 -- CRP229 common accessories and descriptions

No. Name Qt.

1 CRP229

Display Tablet 1

2 Diagnostic Main Cable 1

3 Power adaptor 1

4 OBD II Diagnostic Connector 1

5 Non-16 pin Diagnostic Connector (optional)

Table 2-1 formulates interfaces and indicators of CRP229 display

tablet:

No. Name & Descriptions

1 Communication Indicator

2 Screen Lock/Power Button -- to turn the display tablet on/off

with long press, or lock the screen with short press.

3 Power Indicator

4 Home Button

5 golo Button -- for quick access to IM (Instant Messager)

application

6 TF Card Slot -- to store the TF card.

7 USB Port -- to connect the included power adaptor.

8 Camera Lens

9 Audio Speaker

10 DB15 Connector - to connect the main diagnostic cable

11 Touch Screen

12 Selection Button

13 Conrm Button

14 Back Button
