Tektronix TBS2102 [132/144] Oscilloscope settings that are not reset by default setup

The default osci

lloscope settings (Default Setup)

Oscilloscope settings that are not reset by Default Setup

The Default Setup button does not reset or change the following settings:

Language option

Date and time

Saved setups in memory

Saved reference waveforms in memory

Calibration data

Network, Wi-Fi settings

Probe setup (type and attenuation factor)

Current save folder on the U SB ﬂash drive

114 TBS2000 Series User Manual
