Field or control Description

Copy Trigger Settings to

Search

Sets the search criteria to match the current oscilloscope trigger settings.

Copy Search Settings to

Trigger

Sets the current oscilloscope trigger settings to match the search criteria.

CAN DBC Symbolic Configuration menu

Use this menu to set the CAN .dbc symbol definitions for which to search. This menu is accessed from a CAN Bus Search menu

when a .dbc symbol definition file is loaded on the instrument. Load the .dbc file when you first add and configure the CAN bus.

NOTE. Requires option 5/6-SRAUTO.

Signal Encoded Enables searching for encoded signal values (when selected) or specific values (when not

selected). Use the drop-down list to select from encoded signal types derived from the

installed .dbc file.

Value searching is always available for a signal. Signals, however, are not necessarily encoded,

so searches on signal encoding are not always available.

Value Sets a specific Signal value for which to search. Use knob A to set a value, or double-tap the

field and enter a value using the virtual keyboard.

See also. CAN serial bus search configuration menu (when using a .dbc symbol definition file) on page 288

CAN serial bus configuration menu on page 246

Stop Acquisition if Event

Found

Stops input acquisition when the search event occurs. Default is not enabled.

Source Select the Ethernet bus that you want to search.

Mark On Select the type of information for which to search.
