SPMI serial bus trigger settings panel. Requires option SRPM. Mode & Holdoff panel (Bus Trigger configuration panel) fields
and controls
Field or control Description
Source Select the SPMI bus on which to trigger.
Trigger On Select the type of information on which to trigger.
Slave Address Sets the slave address value on which to trigger.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Reset, Authenticate, Register Read, Register Write, Extended
Register Read, Extended Register Write, Ext. Register Read Long, Ext. Register Write
Long, DD Block Slave Read, or Register 0 Write.
Authenticate Sets the authentication condition on which to trigger.
Available when Trigger On = Authenticate.
Master Address Sets the master address value on which to trigger.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Master Read, Master Write, or DD Block Master Read.
Register Address Sets the register address value on which to trigger.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Master Read, Master Write, Register Read, Register Write,
Extended Register Read, Extended Register Write, Ext. Register Read Long, or Ext.
Register Write Long.
Data Sets the data value on which to trigger.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Master Read, Master Write, Register Read, Register Write,
Extended Register Read, Extended Register Write, Ext. Register Read Long, Ext. Register
Write Long, DD Block Master Read, DD Block Slave Read, or Register 0 Write.
Data Bytes Sets the number of data bytes on which to trigger. Tap the field and use the A knob to change
the value. Or double-tap on the field and use the virtual keypad to enter a value.
Available when Trigger On = Extended Register Read, Extended Register Write, Ext.
Register Read Long, or Ext. Register Write Long.
No Response Sets to trigger on data that is all zeros (no response). All values in the Data field are set to zero
and cannot be edited.
Available when Trigger On = Master Read, Register Read, Extended Register Read, Ext.
Register Read Long, DD Block Master Read, DD Block Slave Read, or Transfer Bus
Ownership.
Menus and dialog boxes
4/5/6 Series MSO Help 463
