Appendix B Hardware Specifications
Item Content
Standards
IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE
802.3z, IEEE 802.3x, IEEE 802.1p, IEEE 802.1q, IEEE 802.1x, IEEE 802.1d,
IEEE 802.1s, IEEE 802.1w, IEEE 802.1ab
IEEE 802.3af/at (For T2500G-10MPS/T2600G-28MPS)
Transmission Medium
10Base-T: UTP/STP of Cat. 3 or above
100Base-TX: UTP/STP of Cat. 5 or above
100Base-FX/LX10/BX10: MMF or SMF SFP Module (For T2500G-10MPS)
1000Base-T: 4-pair UTP (≤100m) of Cat. 5e, and Cat. 6 or above
1000Base-X: MMF or SMF SFP Module (Optional)
LEDs
T2500-28TC: Power, System, 10/100M, 1000M
T2500G-10TS: PWR, SYS, 1000Mbps, 10/100Mbps
T2500G-10MPS: PWR, SYS, PoE MAX, FAN, Speed or PoE, SFP1, SFP2,
PoE, Speed
TL-SG5412F/T2600G-18TS/T2600G-28TS/T2600G-52TS: PWR, SYS,
1000Mbps, Link/Act
T2600G-28MPS: PWR, SYS, PoE Max, FAN, Speed or PoE, 1000Base-X
T2600G-28SQ: PWR, SYS, FAN, 1000Mbps, Link/Act
Operating Temperature 0
℃
to 40
℃
(32°F to 104°F)
Storage Temperature -40
℃
to 70
℃
(-40°F to 158°F)
Operating Humidity 10% to
90%RH Non-condensing
Storage Humidity 5% to
90%RH Non-condensing
