![Tp-Link T2600G-18TS V2 [8/24] 100 1000mbps rj45 port](/views2/1470621/page8/bg8.png)
JetStream L2 Managed Switch
05 Introduction
LED Indication
PoE Max
(When the PoE LED
is on)
On: The remaining PoE power≤7W.
Flashing: The remaining PoE power keeps≤7W after this LED is on for 2 minutes.
Off: The remaining PoE power >7W.
Speed or PoE
(When the Speed
LED is on)
Green On: Running at 1000Mbps, but no activity.
Green Flashing: Running at 1000Mbps and is transmitting or receiving data.
Yellow On: Running at 10/100Mbps, but no activity.
Yellow Flashing: Running at 10/100Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Speed or PoE
(When the PoE LED
is on)
Green On: The port is supplying power normally.
Green Flashing: The supply power exceeds the correponding port's maximum power.
Yellow On: Overload or short circuit is detected.
Yellow Flashing: Power-on self-test failed.
Off: Not providing PoE power on the port.
1000Base-X
On:
A device is linked to the corresponding port.
Flashing:
The corresponding port is transmitting or receiving data.
Off: No device is linked to the corresponding port.
SFP1, SFP2
Green On: A 1000Mbps device is linked to the corresponding port, but no activity.
Green Flashing: A 1000Mbps device is linked to the corresponding port and data is
being transmitted or received.
Yellow On: A 100Mbps device is linked to the corresponding port, but no activity.
Yellow Flashing: A 100Mbps device is linked to the corresponding port and is
transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: Only for T2500G-10MPS.
Console Port (RJ-45/USB)
Designed to connect with the USB port of a computer for monitoring and conguring the switch. For
T2500G-10TS/T2500G-10MPS/T2600G-18TS/T2600G-28TS/T2600G-52TS/T2600G-28MPS/T2600G-28SQ,
the switch has an RJ-45 console port and a micro-USB console port. Console input is active on only
one console port at a time. By default, the micro-USB connector takes precedence over the RJ-45
connector.
10/100Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10Mbps or 100Mbps.
10/100/1000Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or 1000Mbps. For
T2500G-10MPS/T2600G-28MPS, the port can also provide power for PDs.
SFP Port
Designed to install the 1Gbps SFP module. For T2600G-28SQ, ports 17-24 also support 100Mbps SFP
module.
SFP+ Port
Designed to install the 10Gbps SFP+ module.
Combo Ports
