JetStream L2 Managed Switch
02Introduction
The front panel of T2500G-10MPS is shown as the following figure.
Figure 1-3 Front Panel of T2500G-10MPS
LEDs SFP Port10/100/1000Mbps
RJ45 Port
Console Port
(RJ-45/USB)
LED Mode
Switch Button
The front panel of T2500-28TC is shown as the following figure.
Figure 1-4 Front Panel of T2500-28TC
LEDs
10/100Mbps RJ45 Port
SFP Port
10/100/1000Mbps RJ45 Port
Console Port
The front panel of T2600G-18TS is shown as the following figure.
Figure 1-5 Front Panel of T2600G-18TS
10/100/1000Mbps
RJ45 Port
LEDs
Console Port
(RJ45/USB)
SFP Port
The front panel of T2600G-28TS is shown as the following figure.
Figure 1-6 Front Panel of T2600G-28TS
T2600G-28TS
10/100/1000Mbps
RJ45 Port
LEDs
Console Port
(RJ45/USB)
SFP Port
The front panel of The T2600G-52TS is shown as the following figure.
Figure 1-7 Front Panel of T2600G-52TS
ConsoleConsole(USB)
10/100/1000Mbps
RJ45 Port
LEDs
Console Port
(RJ45/USB)
SFP Port
