○ It may not be possible to charge some USB devices,
depending on the type of device.
NAMES OF PARTS (Fig. 1 – Fig. 21)
1
Handle
w
Latch (one side)
2
Switch trigger
e
Latch (both sides)
3
Pushing button
r
Motor
4
Name plate
t
Filter
5
Change lever
y
Terminal
6
Depth gauge
u
Latch
7
Drill bit
i
Charge indicator lamp
8
Front cap
o
Remaining battery
indicator switch
9
Grip
p
Remaining battery
indicator lamp
0
Housing
a
Display panel
!
Side handle
s
Grease
@
LED light
d
Pushing button
#
Terminal cover
f
Cold chisel
$
Motor
g
Bit holder ass'y
%
Vent slot
h
Chuck holder ass'y
^
Battery
j
Battery sliding
grooves
&
RFC indicator lamp
k
Terminal
*
Nozzle
l
Rubber cover
(
Depth adjustment
button
;
USB port
)
Nozzle adjustment
button
z
USB cable
q
Dust box
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
DH36DPA / DH36DPB / DH36DPC / DH36DPD:
Cordless Rotary Hammer
To reduce the risk of injury, user must read
instruction manual.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2002/96/EC
on waste electrical and electronic equipment
and its implementation in accordance with
national law, electric tools that have reached
the end of their life must be collected separately
and returned to an environmentally compatible
recycling facility.
V Rated voltage
n
0
No-load speed
Bpm Full-load impact rate
φ
max
Drilling diameter, max.
kg
Weight
(According to EPTA-Procedure 01/2003)
Concrete
Steel
Wood
Wood screw
Hammering only function
Rotation only function
Rotation and hammering function
Switching ON
Switching OFF
Disconnect the battery
Clockwise rotation
Counterclockwise rotation
Battery
Lights ;
The battery remaining power is over 75%
Lights ;
The battery remaining power is 50% – 75%.
Lights ;
The battery remaining power is 25% – 50%.
Lights ;
The battery remaining power is less than 25%
Blinks ;
The battery remaining power is nearly empty.
Recharge the battery soonest possible.
Blinks ;
Output suspended due to high temperature.
Remove the battery from the tool and allow it to
fully cool down.
Blinks ;
Output suspended due to failure or malfunction.
The problem may be the battery so please
contact your dealer.
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains the
accessories listed on page 262.
Standard accessories are subject to change without notice.
