- 21 - Hardware Installation
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the
power cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1
2
3
5
14 4 13
9
10
11
12
7
8
4
15
1) ATX_12V 9) F_AUDIO
2) ATX 10) CD_IN
3) CPU_FAN 11) SPDIF_IN
4) SYS_FAN1/2 12) SPDIF_OUT
5) PWR_FAN 13) F_USB1/F_USB2
6) BAT 14) COMA
7) SATA3_0/1/2/3/4/5 15) CLR_CMOS
8) F_PANEL
6
