Hikoki SV 13YA [4/108] English
![Hikoki SV 13YA [4/108] English](/views2/1471526/page4/bg4.png)
4
English
MOUNTING AND OPERATION
Action Figure Page
Installing the sanding paper 1 100
Attaching the dust bag 2 100
Switching on and off 3 100
Adjustment of speed (SV13YA only) 4 100
How to hold the random orbit sander 5 100
How to move the random orbit sander 6 101
Installing the polyester buff (optional
accessories)
7 101
Selecting accessories ― 102
Adjustment of speed (SV13YA only)
By adjusting the dial, match the speed to the material and type of work.
Material
Grain
Dial scale
Rough grinding Fine grinding
Paintwork:
Sanding
Repairs
(scratches, rust spots)
Stripping
180
120
40
400
240
80
3 – 6
2 – 4
2 – 4
Wood:
Softwood
Hardwood
Veneers
60 – 80
60
240
240
180
320
3 – 6
3 – 5
2 – 4
Metals:
Aluminium
Steel
Stainless steel
80
60
120
240
240
240
2 – 4
3 – 6
3 – 6
Note: Please use this table as a standard.
After installing new sanding paper
Movement of the sander may tend to become unsteady
after new sanding paper has been installed, because of
the new, coarse grain of the paper. This can be avoided
by slightly tilting the sander forward or backward during
sanding or polishing. Sander movement will become
steady as the sanding paper surface becomes properly
abraded.
MAINTENANCE AND INSPECTION
1. Empting and cleaning the Dust Bag
If the dust bag contains too much saw dust, dust
collection will be aff ected. Empty the dust bag when it
gets full.
Remove the dust bag, open the fastener, and dispose of
the contents.
2. Inspecting the sanding paper
Since use of worn-out sanding paper will degrade
effi ciency and cause possible damage to the pad,
replace the sanding paper as soon a excessive abrasion
is noted.
3. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
4. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool. Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
5. Replacing supply cord
If the supply cord of Tool is damaged, the Tool must be
returned to HiKOKI Authorized Service Center for the
cord to be replaced.
6. Servicing
Consult an authorized Service Agent in the event of
power tool failure.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
GUARANTEE
We guarantee HiKOKI power tools in accordance with
statutory/country specifi c regulation. This guarantee does
not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the power tool, undismantled, with the GUARANTEE
CERTIFICATE
found at the end of this Handling instruction,
to a HiKOKI Authorized Service Center.
Installing the sanding paper
Since the attachment is a hook-and-loop type, the
sanding paper can be installed easily by just pressing it
onto the pad. When installing the sanding paper, in order
to match it to the holes in the pad, gently fold it along the
axis of two holes as shown in Fig. 1.
Next, use the holes along the fold as a guide to match
the sanding paper and the pad. Finally, press the entire
sanding paper uniformly onto the pad.
0000Book_SV13YA.indb 40000Book_SV13YA.indb 4 2017/12/07 11:28:352017/12/07 11:28:35
