- 76 -GA-8IE2004 Series Motherboard
English
Intel Chipset Software Installation Utility
Tell the operating system how the chipset components will be configured.
Intel Application Accelerator
Designed to improve performance of the storage sub-system and overall system performance
USB Patch for WinXP
This patch driver can help you to resolve the USB device wake up S3 hang up issue in XP
RealTek LAN Driver*
Realtek 10/100 LAN driver for 81XX sereis chips
RealTek ALC101A/201A/202/650/655 AC97 Codec Driver
For Intel
®
ICH/ICH2/ICH4/ICH5/ICH5R AC97 audio
Item Description
Driver installation finished !
You have to reboot system !
For USB2.0 driver support under Windows XP operating system, please use Windows Service
Pack. After install Windows Service Pack, it will show a question mark "?" in "Universal Serial Bus
controller" under "Device Manager". Please remove the question mark and restart the system
(System will auto-detect the right USB2.0 driver).
* For GA-8IE2004-L only.
