Tp-Link T1500G-10PS V2 [2/2] Frequently asked questions faq

The Power LED should be lit when the power system is working normally. If the

Power LED is not lit, please check as follows:

A1:

Make sure the AC power cord is connected to the switch with power source

properly.

A2:

Make sure the voltage of the power supply meets the requirements of the

input voltage of the switch.

A3:

Make sure the power source is ON.

Standard

IEEE802.3i, IEEE802.3u, IEEE802.3ab,

Gigabit Ethernet: 2000Mbps (Full Duplex)

10Base-T:

UTP Cat. 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω

STP (maximum 100m)

100Base-TX:

UTP of Cat. 5 or above (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

1000Base-T:

UTP of Cat. 5e or above (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

Automatically learning, automatically aging

10Base-T: 14881pps/Port

100Base-Tx: 148810pps/Port

1000Base-T: 1488095pps/Port

Protocol

Data Transfer Rate

Network Media (Cable)

Number of Ports

LED Indicators

Transfer Method

Frame Forward Rate

PoE Ports (RJ45)

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1) This device may not cause harmful interference.

CAN ICES-3 (A)/NMB-3(A)

General Specications

Q1. The Power LED is not lit.

Please try the following:

A1:

the device.

A2:

Make sure the connected device is turned on and works normally.

A1: Make sure that this PoE device complies with IEEE 802.3af/IEEE 802.3at.

A2: Try another PoE port on the switch.

A3: Pay attention to PoE priority. If the total power consumption of PoE powered

devices exceeds 53W, a priority will be set among the ports. Ports with a smaller

port number will have higher priority. For example, Port 1, 2 and 5 are each

consuming 15.4W. If an additional powered device consuming 12W is connected

please visit http://www.tp-link.com/support, or simply scan the QR

code.

directives 2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.

The original EU declaration of conformity may be found at http://www.tp-link.com/en/ce.

EU declaration of conformity

Explanation of the symbols on the product label

Продукт сертифіковано згідно с правилами системи

УкрСЕПРО на відповідність вимогам нормативних

документів та вимогам, що передбачені чинними

законодавчими актами України.
