Name

Status

Indication

PoE Max

The power of all the connected PoE ports is between

103W and 110W. No power may be supplied if additional

PDs are connected.

Flashing

The power of all the connected PoE ports is ≥110W.

Off

The power of all the connected PoE ports is <103W.

FAN

Green

The fan works properly.

Yellow

The fan doesn't work properly.

2.2.2 Rear Panel

 TL-SG105E/TL-SG108E/TL-SG108PE

The rear panel of TL-SG105E/TL-SG108E/TL-SG108PE features a power socket and a

Kensington Security Slot (marked with

). TL-SG105E also has a Reset button located on the

rear panel.

Figure 2-7 Rear Panel of

TL-SG105E

Figure 2-8 Rear Panel of

TL-SG108E

Figure 2-9 Rear Panel of TL-SG108PE

 Reset: With the switch powered on, press this button for five seconds or above to reset the

software setting back to factory default setting. (For TL-SG105E only)

 Kensington Security Slot: Secure the lock (not provided) into the security slot to prevent

the device from being stolen.
