GA-8GEM800 Motherboard - 30 -
English
The Main Menu (For example: BIOS Ver. : E2)
Once you enter Award BIOS CMOS Setup Utility, the Main Menu (as figure below) will appear on the
screen. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.
If you can't find the setting you want, please press "Ctrl+F1" to access hidden advanced
options.
n Standard CMOS Features
This setup page includes all the items in standard compatible BIOS.
n Advanced BIOS Features
This setup page includes all the items of Award special enhanced features.
n Integrated Peripherals
This setup page includes all onboard peripherals.
n Power Management Setup
This setup page includes all the items of Green function features.
n PnP/PCI Configuration
This setup page includes all the configurations of PCI & PnP ISA resources.
n PC Health Status
This setup page includes information about the system autodetected temperature, voltage, fan,
speed.
n Frequency/Voltage Control
This setup page is to control CPU clock and frequency ratio.
n Top Performance
If you wish to maximize the performance of your system, enable Top Performance.
n Load Fail-Safe Defaults
Fail-Safe Defaults indicate the value of the system parameters with which the system would be
in safe configuration.
n Load Optimized Defaults
Optimized Defaults indicate the value of the system parameters with which the system would be
in best performance configuration.
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
} Standard CMOS Features
} Advanced BIOS Features
} Integrated Peripherals
} Power Management Setup
} PnP/PCI Configurations
} PC Health Status
} Frequency/Voltage Control
Top Performance
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
Set User Password
Save & Exit Setup
Exit Without Saving
Esc: Quit higf: Select Item
F8: Q-Flash F10: Save & Exit Setup
Time, Date, Hard Disk Type...
