- 32 -8VT800-RZ/8VT800-RZ-C Motherboard

English

Frequency/Voltage Control

CPU Clock Ratio

This option will not be shown or not be available if you are using a CPU with the locked ratio.

This setup option will automatically assign by CPU detection.

For C-Stepping P4: 8X,10X~24X default: 15X

For Northwood CPU: 12X~24X default: 16X

The option will display "Locked" and read only if the CPU ratio is not changeable.

Auto Detect PCI/DIMM Clk

Disabled Disable auto detect PCI/DIMM Clk.

Enabled Enable auto detect PCI/DIMM Clk. (Default value)

Spread Spectrum

Disabled Disable spread spectrum.

Enabled Enable spread spectrum. (Default value)

CPU Host Clock Control

Note: Please note that if your system is overclocked and cannot restart, please wait 20secs.

for automatic system restart or clear the CMOS setup data and perform a safe restart.

Disabled Disable CPU Host Clock Control. (Default value)

Enabled Enable CPU Host Clock Control.

CPU Clock

Incorrect using it may cause your system broken. For power End-User use only!

100~166 For 100MHz CPU:Set CPU Clock to 100MHz~166MHz.

133~199 For 133MHz CPU:Set CPU Clock to 133MHz~199MHz.

200~250 For 200MHz CPU:Set CPU Clock to 200MHz~250MHz.

ø This item will be available when "CPU Host Clock Control" is set to Enabled.

Frequency/Voltage Control

CPU Clock Ratio [15X]

Auto Detect PCI/DIMM Clk [Enabled]

Spread Spectrum [Enabled]

CPU Host Clock Control [Disabled]

ø CPU Clock 100MHz

DRAM Clock [By SPD]

AGP OverVoltage Control [Auto]

DIMM OverVoltage Control [Auto]

higf: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Save Default F7: Optimized Defaults

Item Help

Menu Level}
