- 33 - BIOS Setup
English
DRAM Clock (MHz)
Please set DRAM Clock according to your requirement.
Incorrect using it may cause your system broken. For power End-User use only!
100-DDR200 If you use DDR200 DRAM module, please set "100-DDR200".
133-DDR266 If you use DDR266 DRAM module, please set "133-DDR266".
166-DDR333 If you use DDR333 DRAM module, please set "166-DDR333".
200-DDR400 If you use DDR400 DRAM module, please set "200-DDR400".
By SPD Set Memory frequency by DRAM SPD data. (Default value)
AGP OverVoltage Control
Increase AGP voltage may get stable for Over_Clock. But it may damage to AGP Card when
enable this feature.
Auto Supply voltage as AGP Card reguired. (Default value)
+0.1V Set AGP OverVoltage Control to +0.1V.
+0.2V Set AGP OverVoltage Control to +0.2V.
+0.3V Set AGP OverVoltage Control to +0.3V.
DIMM OverVoltage Control
Increase DRAM voltage may get stable for Over_Clock. But it may damage to DRAM module
when enable this feature.
Auto Supply voltage as DRAM module reguired. (Default value)
+0.1V Set DIMM OverVoltage Control to +0.1V.
+0.2V Set DIMM OverVoltage Control to +0.2V.
+0.3V Set DIMM OverVoltage Control to +0.3V.
