Tp-Link TL-SF1008P V1 [10/16] Power on

2.2 Power On

The TL-SF1008P Switch can be used with DC power supply.

Powering on the Switch, it will automatically initialize and its LED

indicators will respond as follows:

1) All the LED indicators except PoE ports LED will light syn-

chronously at first, then all of them included Link/Act LED

(green), 100Mbps LED (green) and PoE MAX LED (red), will

light off at once, which indicates the system initialized well.

2) The Power indicator will light all the time.

Note

If the LED indicators don’t respond as described above, please

check the power supply and its connection.

Chapter 3. Identifying External Components

This Chapter describes the front panel, rear panel and LED indi-

cators of the Switch.

3.1 Front Panel

Figure 3-1 TL-SF1008P Switch Front Panel

The Switch’s LEDs are located on the front panel.
