Tp-Link TL-SF1008P V1 [12/16] Rear panel

(green)

There is a 100Mbps device

connected to the corresponding

port.

100Mbps

(port-1~port-8)

Off

There is a 10Mbps device

connected to the corresponding

port, or there is no device

connected to the corresponding

port.

Note

If all PoE PDs power consumption is >= 53w, a priority* will be

arranged among the PoE ports like port-1 > port-2 > port-3 > port-4,

then the system will cut off the power of the lowest-priority port.

3.2 Rear Panel

Figure 3-2 TL-SF1008P Switch Rear Panel

*Priority: This function will help protect the system when the system power is

overloaded. For example, Port 1, 2 and 4 is using 15.4w (maximum

power for per port is 15.4W), the system power is 46.2w in total. If

there is an additional PD inserted to Port 3 with 10w, then the system

will cut off the power of Port 4 because of the overloaded power, this

means Port 1, 2 will use 15.4w, and Port3 will use 10w ,no power will

be supplied to Port 4.
