MD JETSTREAM NO: U.G.M.-MD-04/99
REV: 0
SERVICE MANUAL
PAGE: 6
Standard casing/insulation box ( Common for all models)
Part name
Number / Quantity Pos. Number in exploded drawing
Upper front casing + handle + plastic pin 1 60,119,120
(Heatline arm + nut M4 + washer) 1+2+2 103+112+111
Lower front casing + plastic pin 1 115,120
Front casing insulations 1+1 88
Setscrew M8x20 4 122
Washer A9 4 123
Smokehood insulations 1+1 92
Smokehood insulations support strip 1 94
Distance piece 2 124
Nut M12 2 9
Washer M12 2 10
Upper casing support 1 118
Self tapping screw S3.8x13 6 108
Flange, burner mounting plate 1 116
Side/top casing/insulation box (Spesific for all models)
Right / hand side casing 1+1 68
(Plastic clip/M4 pin+ nut + washer) 8/4+4+4 121 / 78+112+111
Top casing 1 64
Boiler block insulation 80 mm 1 117
Strip insulation 2/3 125
Spring insulation 2/3 126
Insulation below boiler block 1 93
Coverplate for cleaning cover 1 33
Cleaning brush 1 101
Cleaning brush handle 1 102
Retarder box
Baseframe (support girders) 2/4 19
Retarder second pass (2 bladed module) 4/8 95
Retarder second pass (3 bladed module) 4/8 99
Retarder third pass (MD 4, 5, 6, 7) 4 97
Following table shows the usage of second pass retarders:
NOTE: For each MD boiler, four groups of second pass retarder modules are prepared before installation. One group
is used for one gas passages. Likewise, there are four third passages for four corner passages.
PREPARED BY APPROVED BY DATE OF APPROVAL DELIVERED TO
Murat GEDK Metin ARMAN
Second pass retarder
modules
MD4 MD5 MD6 MD7 MD8 MD9
2 bladed module 2 1
3 bladed module 1 2 2 2 2
