GA-8I915ME Series Motherboard - 10 -
English
Motherboard GA-8I915ME Series motherboard
-GA-8I915ME-GV / GA-8I915ME-GL / GA-8I915ME-C / GA-8I915ME-G
CPU Supports the latest Intel
®
Pentium
®
4 LGA775 CPU
Supports 800 / 533MHz FSB
L2 cache varies with CPU
Chipset Northbridge: Intel
®
915GV /915GL /910GL /915G Express chipset
Southbridge: Intel
®
ICH6
Supported on the Win 2000/XP operating systems
Memory 2 DDR DIMM memory slots (supports up to 4GB memory)
(Note 1)
Supports dual channel DDR400/333 DIMM
Supports 2.5V DDR DIMM
Slots 1 PCI Express x 16 slot
(Note 2)
1 G.E.A.R. slot
(Note 3)
2 PCI slots
IDE Connections 1 IDE connection (UDMA 33/ATA 66/ATA 100), allows connection of 2 IDE
devices
Supported on the Win 2000/XP operating systems
FDD Connections 1 FDD connection, allows connection of 2 FDD devices
Onboard SATA 2 Serial ATA connections
Supported on the Win 2000/XP operating systems
Peripherals 1 parallel port supporting Normal/EPP/ECP mode
1 VGA port, onboard COM1/COM2 connection
8 USB 2.0/1.1 ports (rear x 4, front x 4 via cable)
1 front audio connector
1 PS/2 keyboard port
1 PS/2 mouse port
Onboard LAN Onboard RTL8100C chip (10/100 Mbit)
Onboard RTL8110S chip (10/100/1000 Mbit)
1 RJ 45 port
Supported on the Win 2000/XP operating systems
Onboard Audio Realtek ALC655 CODEC
Supports Line In ; Line Out ; MIC In
Supports 2 / 4 / 6 channel audio
SPDIF In / Out connection
CD In / AUX In connection
Supports Jack-Sensing function
Supported on the Win 2000/XP operating systems
I/O Control IT8712F
1-2 Feature Summary
Only for GA-8I915ME-GV.
Only for GA-8I915ME-GL.
Only for GA-8I915ME-C.
Only for GA-8I915ME-G.
