GA-8I865GVM(F)-775 Motherboard - 34 -
English
2-3 Integrated Peripherals
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Integrated Peripherals
On-Chip Primary PCI IDE [Enabled]
On-Chip Secondary PCI IDE [Enabled]
On-Chip SATA [Auto]
x SATA P ort0 configure as SATA Port0
SATA P ort1 configure as SATA Port1
USB Controller [Enabled]
USB 2.0 Controller [Enabled]
USB Keyboard Support [Disabled]
USB Mouse Support [Disabled]
AC97 Audio [Auto]
Onboard H/W 1394* [Enabled]
Onboard H/W LAN [Enabled]
Onboard LAN Boot ROM [Disabled]
POWER ON Function [Disabled]
Onboard Serial P ort 1 [3F8/IRQ4]
Onboard Serial P ort 2 [2F8/IRQ3]
UART Mode Select [Normal]
x UR2 Duplex Mode Half
Onboard Parallel Port [378/IRQ7]
higf: Move Enter: Select +/-/PU/P D: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Default F7: Optimized Defaults
Item Help
Menu Level}
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Integrated Peripherals
higf: Move Enter: Select +/-/PU/P D: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Default F7: Optimized Defaults
Item Help
Menu Level}
On-Chip Primary PCI IDE
Enabled Enable onboard 1st channel IDE port. (Default value)
Disabled Disable onboard 1st channel IDE port.
On-Chip Secondary PCI IDE
Enabled Enable onboard 2nd channel IDE port. (Default value)
Disabled Disable onboard 2nd channel IDE port.
On-Chip SATA
Disabled Disable onboard Seria ATA function.
Auto When there is no device to be plugged in IDE1 or IDE2, SATA controller will
remap to IDE controller. (Default value)
Manual Set SATA mode manually from "SATA Port0 configure as" item.
Parallel Port Mode [PRINTER]
x ECP Mode Use DMA 3
* Only for GA-8I865GVMF-775.
