Fluke 115С [9/26] True rms multimeters rotary switch positions

True-rms Multimeters

Rotary Switch Positions

Switch

Position

Measurement Function Model

Automatically selects ac or dc volts based on the sensed input with a low

impedance input.

117C

Hz (button)

AC voltage from 0.06 mV to 600 V.

Frequency from 5 Hz to 50 kHz.

115C & 117C

DC voltage from .001 V to 600 V. 115C & 117C

AC voltage from 6.0 to 600 mV, dc-coupled. DC voltage from 0.1 to 600 mV.

115C & 117C

Ohms from 0.1 Ω to 40 MΩ.

115C & 117C

Continuity beeper turns on at <20 Ω and turns off at >250 Ω. 115C & 117C

Diode Test. Displays OL above 2.0 V. 115C & 117C

Farads from 1 nF to 9999 μF. 115C & 117C

Hz (button)

AC current from 0.1 to 10 A (>10 to 20 A, 30 seconds on, 10 minutes off).

>10.00 A display flashes. >20 A, OL is displayed. DC-coupled.

Frequency from 45 Hz to 5 kHz.

115C & 117C

DC current from 0.001 A to 10 A (>10 to 20 A, 30 seconds on, 10 minutes off).

>10.00 A display flashes. >20 A, OL is displayed.

115C & 117C

Non-contact sensing of ac voltage.

117C

Note: All ac functions and Auto-V LoZ are true-rms. AC voltage is ac-coupled. Auto-V LoZ, AC mV and AC

amps are dc coupled.
