Crate VTX30B [7/8] System block diagram
![Crate VTX30B [7/8] System block diagram](/views2/1004841/page7/bg7.png)
7
VTX30
Two-Channel Guitar Amplifier with DSP
System Block Diagram:
INPUT
FOOTSWITCH
JACK
SOLO/
CLEAN
LOWLEVEL MID HIGH
LEVEL
BUFFER
CLEAN
POWER
AMP
EXTENSIO
N
SPEAKER
SPEAKER
TUNER
A BC D EF G
GAIN SHAPE LEVEL
SOLO
DSP
MODE
CD
INPUT
