14
џ If you choose not to return to default pixel pattern, select “No” and press the
controller.
џ To exit the main menu, keep the controller pressed for two seconds or wait 10
seconds to exit automatically.
Attention! One or two pixels in the form of bright white or black 1-2 pixels dots
are allowed on the display of thermal imager. These pixels cannot be repaired
and are not a defect.
Restore of default settings
To return to default settings:
џ Rotate the controller to select “Default settings”.
џ Press the controller (11).
џ To activate return to default settings, rotate the controller to select “Yes”,
press the controller button.
The following settings will return to their original status before the changes:
Operating mode – “Forest”;
Calibration mode – automatic;
Weapon selection – 1;
Selection of preloaded reticle – 1 (for all weapon types);
Reticle colour – black;
Brightness of menu symbols – 5;
Video output – off;
Display brightness level – 10;
Display contrast level – 6;
Digital zoom – off;
Image inversion – off;
Function “PiP” – off
Rangefinding indicator - 1
Units of measurement - metre
To cancel return to default settings, select “No” and press controller button to
confirm.
Note: zeroing coordinates do not return to default for all types of weapon.
Return to default defective pixel pattern
џ If you wish to return to the default defective pixel pattern (i.e. restore all
defective pixels previously repaired), select icon in the pop-up submenu
and press the controller.
џ Options “Yes” and “No” appear on the right of the icon.
џ Rotate the controller to select “Yes” and press the controller.
15
Function “Digital zoom”
On the display you can see the full magnification which optical is a product of the
magnification digital zoom.and x2 / x3 / x4
Digital zoom ratio
Full magnification
Optical
magnification
x2 x4
4,4x
5,6x
8,8x
11,2x
2.2x
2.8x
x3
6,6x
8,4x
MENU M3:
Selection of rangefinding indicator
џ This option allows you to switch between the three types of indicators for the
rangefinder.
џ Push and rotate the controller to select the number of indicator.
џ Press briefly the controller to confirm your choice.
џ Upon start the aiming reticle disappears from the display, and rangefinding
indicator only is shown instead.
џ In 4 seconds of inactivity the aiming reticle reappears on the display.
Selection of units of measurement
This menu option allows you to switch units of measurement – metres or
yards.
џ Rotate the controller to select “M” (metres) or “Y” (yards).
џ Confirm your choice by a short press of the controller button.
џ Icon of unit of measurement is shown next to the distance readings.
“Digital zoom” has two modes:
Brief press of the ON (3) button (PiP should be off) .
Change the digital zoom values cyclically with a short press of the ON button:
off => x2 => x3 => x4 => off.
Standard mode:
You can also operate the Digital zoom with the remote control (PiP should be
off) – please refer to section “Remote control activation” in menu M2.
Continuous zoom mode:
Press briefly the controller to select “continuous zoom” mode. The full
magnification changes with an increment of 0.1x when rotating the controller.
Operating principle of the “Standard zoom” mode depending on the actual
value of the continuous zoom works as follows.
1st press
ON
4.4x
8.8x
x2.2
Actual
value
4.4x
8.8x
x3.6
6.6x
x2.2
x5.0
6.6x
6.6x
8.8x
2nd press
ON
3rd press
ON
4th press
ON
2.2x
2.2x
4.4x
џ (7)The riflescope is equipped with a built-in rangefinder , allowing you to
measure distance to objects up to 1000m away.
џ How the rangefinder works:
BUILT-IN RANGEFINDER
