YUKON Signal N320 RT [5/14] Страница 5
![YUKON Signal N320 RT [5/14] Страница 5](/views2/1484716/page5/bg5.png)
OPERATION
7
Remove the lens cover from the objective lens (1).
Turn the unit on by briefly pressing the button. The display shows the battery icon ON (2) charge .
To turn the display off during operation, press and hold down the button for more than one second. ON
The display will show a message. “Display off”
To turn the display on, press iefly the button. br ON
To turn the unit off, press and hold down the button for more than three second. The display shows ON
message , countdown will start from 3 to seconds, and the unit turns off. “Switch off” 1
Achieve a crisp image of the icons on the display by rotating the eyepiece diopter adjustment ring . (7)
Locate an object at a certain distance, achive a crisp image of the object by rotating the objective lens .(1)
To adjust display brightness, hold down the ZOOM (4) button. Use the navigation buttons (IR; REC) to
select icon , enter the submenu with a brief press of the ZOOM button.
Adjust the image brightness with navigation buttons REC (5) и IR (3) (adjustment range is 0 to 20).
When changing the viewing distance, achieve a sharp image by rotating the objective lens . There is (1)
no need to rotate the eyepiece - you have already made the necessary individual adjustment.
When the device starts, the built-in IR Illuminator (6) switches on automatically (first level). Press the IR
(3) button successively to change power level (3 levels are available). The corresponding icon
will appear in the upper part of the display .
To turn the IR Illuminator off, press and hold down the button for two seconds. The IR icon will IR
disappear.
To activate the digital zoom, briefly press the button. Full magnification is constantly shown in ZOOM (4)
the upper part of the display, for example “4.5x”.
Press the ZOOM button again to return to the initial magnification.
To start video recording, press briefly the REC (5) button.
6
5
DESCRIPTION OF CONTROLS
Button
ON
ZOOM
REC
Operating mode
The unit is off
The unit is in modeVideo / Photo
Video
st
1 short press
Turns the unit on
Turns the Wi-Fi on
nd
2 short press
Turns the Wi-Fi on
Turns the Wi-Fi off
Long press
Turns the display off
(hold longer than 1 sec)
Turns the unit off
(hold longer than 3 sec)
Digital zoom activation
Switch between files – rightwards navigation
Return to the beginning of file under review
Switch to Photo Mode
The unit is in Review mode
File deletion prompt See description of Review Mode
Review
Enter / Exit the menu
—
Video
Review
Start video recording Stop video recording
Image capture
Switch to Review Mode
Recorded video review Pause video review
Switch to Video Mode
IR
Turns the IR Illuminator off
Video
Review
Switch between IR Illuminator modes
Switch between files - leftwards navigation.
Return to file currently viewed
—
6
Image capture
Display off mode
Turns the display on
Turns the Wi-Fi on/off
