17
ow to use washer
H
Start/Pause
Detecting
• This Start/Pause button is used to start
wash cycle or pause the wash cycle.
• If temporary stop of wash cycle is needed,
press the Start/Pause button.
• When in Pause, the power is turned off
automatically after 4 minutes.
• NB. The door will not open before 1 to 2
minutes when Pause is selected,
or at the end of the wash cycle.
• While the "Detecting" is shown in the display
the machine rotates slowly and detects how
many laundries are loaded in the drum. It
will take a few seconds.
• Available in Cotton, Cotton Quick and
Synthetic.
Door Lock
• Lights whenever the door of the washer is
locked.
• The door can be unlocked by pressing the
Start/Pause button to stop the washer.
• The door can be opened after a short delay.
Option
• By pressing the
Option button, all
Option functions may
be selected.
• If the laundry is heavily soiled, “Pre Wash”
course is effective.
• Pre Wash is available in Cotton, Cotton
Quick, Synthetic, Bio Care, Baby Care and
Boiling Care.
• For high effectiveness or more purity in
rinse operation you can choose Medic Rinse
option.
• It can be chosen in all course with the
exception of Quick 30, Hand Wash/Wool,
Duvet, Delicate and Bulky.
• If you want to prevent crease, select this
button with spin speed.
The required lamp will light up for
identification.
• If the laundry is heavily soiled “Intensive”
option is effective.
• By selecting the Intensive option, the wash
time may be extended, depending on the
program selected.
1. Start
1. Medic Rinse
2. Pre Wash
3. Intensive
4. Crease Care
2. Pause
