20
4. Feeding Part Components
Ref.NO
Parts.NO
零件名称
Description
6003
1
6003/4-01
紧固螺钉
Screw M5X5
2
2
6003/4-02
套管
Collar
1
3
6003/4-03
套管弹簧
Collar Spring
1
4
6003/4-04
送料调节偏心轮
Feed adjusting eccentric
1
5
6003/4-05
偏心轮螺钉
Screw
2
6
6003/4-06
送料调节滑块座
Feed adjusting slide seat
1
7
6003/4-07
调节板
Adjusting plate
1
8
6003/4-08
固定支轴
Fixed shaft
1
9
6003/4-09
滑块座调节螺母
Nut M3
2
10
6003/4-10
滑块座调节螺钉
Screw
2
11
6003/4-11
送料调节滑块
Slide block
1
12
6126
螺钉
Screw M6X8
2
13
6131
O 型密封圈
Seal Ring
1
14
6003/4-14
偏心轴
Eccentric Shaft
1
15
6003/4-15
送料调节拉簧
Spring
1
16
6003/4-16
送料调节拉簧螺钉
Screw M5X15
1
17
6115
送料连杆
Connection Rod
1
18
6128
连接轴座螺钉
Screw M4X14
1
19
6127
连接轴座
Connection Block
1
20
6118
挡圈螺钉
Screw M4X10
2
21
6116
挡圈
Collar
1
22
6117
送料连杆销
Pin
1
23
6003/4-23
送料调节按钮拨杆
Feed adjusting lever
1
24
6003/4-24
O 型密封圈
Seal Ring
1
25
6003/4-25
紧固螺钉
Screw M5X5
1
26
6003/4-26
送料调节按钮
Feed adjusting button
1
27
6132
关节轴承螺钉
Screw
1
28
6133
关节轴承
Connection Block
2
29
6135
螺母
Nut M6
3
30
6134
连接螺杆
Connection Rod M6X75
1
31
6285
垫圈
Washer
1
32
挡圈螺钉
Screw 1/4X40 L=4
2
33
6290
挡圈
Collar
1
34
6092
单向轴承 HF1516
one way bearing
5
35
6249
关节轴承连接螺钉
Screw M6X20
1
36
6003/4-36
传动曲柄
Transmission outer ring
1
37
6003/4-37
传动曲柄垫圈
Washer
1
38
6003/4-38
送料轴
Shaft Assembly
1
39
6003/4-39
送料轴套
Feeding shaft sleeve
1
40
6112
送料盘
Back cup
1
41
6113
送料盘螺钉
Screw 11/64X40
2
