22
5. Pressing Front Wheel Part Components
Ref.NO
Parts.NO
零件名称
Description
6003
1
6166
调节销
Tapped Rod
1
2
6176
挡料板（B）
Work Guide
1
3
6174
挡料板座螺钉
Work Guide Screw M5X14
1
4
6169
垫圈
Washer
4
5
6172
挡料板座
Guide Connector
1
6
6173
挡料板螺钉
Work Guide Screw M5X12
1
7
6165
拉簧调节螺钉
Screw M6X50
1
8
6168
挡料板座支架螺钉
Screw M5X16
2
9
6003/5-09
挡料板座支架
Guard Connector
1
10
6163
压料拉簧
ExTension Spring
1
11
6160
压杆导架滑块
Slide Block
1
12
6156
压杆导架
Pressure Lever
1
13
6095
垫圈
Washer
1
14
6158
螺钉
Screw M6X20
1
15
6230
螺钉
Screw M6X6
1
16
6164
拉簧销
Pin
1
17
6185
螺钉
Screw M6X14
1
18
6184
垫圈
Washer
1
19
6161
压杆导架座
Pressure Lever
1
20
6182
O
型密封圈
Seal Ring
1
21
6183
压料手柄
Press Shaft Block
1
22
6162
压杆导架座螺钉
Screw M8X16
1
23
6003/5-23
压料手柄轴
Base Shaft
1
24
6180
压料摆动曲柄螺钉
Screw M8X25
1
25
6179
压料摆动曲柄
Bass Shaft Table
1
26
6177
拉杆
Pull Rod
1
27
6175
挡料板（A）
Work Guide M4X12
1
28
6014
垫圈
Washer
1
29
6170
过线钩
Thread Tension Guard
1
30
6094
紧定螺钉
Screw
1
