零件号码 零件名称 件数 备注 零件号码 零件名称 件数 备注
Parts No. Name of Parts
QTY Parts No. QTY Remarks
5100120100
上
轴----------------
-
Main Shaft-----------------------------
-
1 ZSA16025
螺
丝----------------
-
Screw (1/4-40×6)---------------
-
2
5100120500
后
套油盖组件----- Oil Seal--------------------------------- 1 ZSB16031
螺
丝----------------
-
Screw (1/4-40×11)--------------
-
2
51001208H0
凸
轮曲柄----------- Counter Weight-----------------------
-
1 ZSB18011
螺
丝----------------
-
Screw (9/32-28×11)------------
-
1
5100121000
针
棒连接杆-------- Needle Bar Crank Rod---------------
-
1 ZSK09005
螺
丝----------------
-
Screw (9/64-40×6)--------------
-
1
5100121300
针
棒连接轴-------- Needle Bar Crank--------------------- 1
5100122100
偏
心轮盖板-------- Thrust Collar--------------------------
-
1
5100122300
上
轮----------------
-
Flywheel Asm-------------------------
-
1
5100122600
固
定环-------------- Thrust Collar Asm--------------------
-
1
5100190105
天
秤组件----------- Thread Take-up Complete----------- 1
5100190500
挡
油环-------------- Rubber---------------------------------- 1
5100192000
天
秤架-------------- Lever-----------------------------------
-
1
5100192200
销
油线-------------- Oil Thread-----------------------------
-
1
5100354200
油
量调节销-------- Oil Amount Adjusting Pin----------- 1
5100354300
调
节销圈----------- Oil Adjusting Collar------------------ 1
5100120401
上
轴后套----------- Main Shaft Bushing,Rear------------
-
1
51001220H4
偏
心轮-------------- Feed Drive Eccentric Cam----------
-
1
BN081208
滚
针轴承----------- Roller Bearing------------------------- 2
FD1061-0A
天
秤固定销-------- Thread Take-up Crank Shaft Asm------
-
1
FD1101-0A
上
轴前套----------- Front Bushing ------------------------
-
1
FD1102-0A
上
轴中套----------- Intermediate Bushing ---------------- 1
FD1103-0A
中
套接头----------- Joint------------------------------------- 1
OPP0029178 O型圈--------------
-
Rubber Ring---------------------------
-
1
OPP0044240
定
位O型圈--------
-
Rubber Ring---------------------------
-
1
RB200200
挡
圈----------------
-
Snap Ring------------------------------
-
1
XB106001
油
棉----------------
-
Roller Felt-----------------------------
-
1
ZSA15010
螺
丝----------------
-
Screw (15/64-28×13)----------------- 2
ZSA15037
螺
丝----------------
-
Screw (15/64-28×8.5)----------------
-
1
ZSA16022
螺
丝----------------
-
Screw (1/4-40×7)---------------------
-
2
ZSA18002
螺
丝----------------
-
Screw (9/32-28×11.5)----------------
-
1
ZSB09014
螺
丝----------------
-
Screw (9/64-40×6)-------------------- 2
2.CS-7500 上轴挑线机构 MAIN SHAFT THREAD TAKE-UP LEVER MECHANISM
Remarks
Name of Parts
5
