零件号码 零件名称 件数 备注 零件号码 零件名称 件数 备注
Parts No. Name of Parts
QTY Parts No. QTY Remarks
5100132000
竖
轴----------------- Upright Shaft--------------------------
-
1 ZSB11026 螺丝----------------
-
Screw (11/64-40×10)-----------
-
1
5100132100
竖
轴上套----------- Upright Shaft Bushing Upper-------
-
1 ZSB12053 螺丝----------------
-
Screw (3/16-28×9)--------------
-
1
5100132200
竖
轴下套----------- Upright Shaft Bushing Lower------- 1 ZSH16005 螺丝----------------
-
Screw (3/16-28×10)------------- 2
5100133000
上
轴伞齿轮-------- Gear Asm------------------------------
-
1
5100133100
竖
轴上伞齿轮----- Pinion Asm----------------------------
-
1
5100140800
针
棒线挂----------- Needle Thread Guide----------------- 1
5100140900
针
棒钳-------------- Needle Bar Connecting Asm--------
-
1
5100180100
下
轴----------------- Hook Driving Shaft------------------- 1
5100180300
下
轴前套----------- Hook Driving Shaft Bush------------ 1
5100180500
下
轴后套----------- Bushing, Rear-------------------------
-
1
5100180600
竖
轴下伞齿轮----- Gear Asm------------------------------
-
1
5100180700
下
轴伞齿轮-------- Pinion Asm----------------------------
-
1
5100183200
梭
芯----------------- Bobbin---------------------------------- 1
5100184900
固
定环-------------- Thrust Collar Asm--------------------
-
1
51001858T0
牛
角----------------- Bobbin Case Positioning Finger----
-
1
5100188200
挡
油圈-------------- Thrust Collar Asm--------------------
-
1
5100354400
下
轴限油螺丝----- Oil Seal Screw------------------------
-
1
5100354500
油
芯----------------- Oil Wick-------------------------------
-
1
E6105-0A
梭
壳----------------- Bobbin Case Asm--------------------- 1
FD1070-0A
针
棒----------------- Needle Bar-----------------------------
-
1
FD1077-0A
针
棒油盖----------- Rubber Plug---------------------------
-
1
FD1082-0A
导
引滑块----------- Slide Block----------------------------
-
1
INDB*1#11
针
-------------------- Needle----------------------------------
-
1
KHS12-GTHPD
旋
梭----------------- Hook Asm-----------------------------
-
1
ZSA11004
螺
丝----------------- Screw (11/64-40×3.5)----------------
-
2
ZSA15016
螺
丝----------------- Screw(15/64-28x7)-------------------
-
1
ZSA16022
螺
丝----------------- Screw (1/4-40×7)---------------------
-
6
ZSB08010
螺
丝----------------- Screw (1/8-44×4.6)-------------------
-
1
ZSB09014
螺
丝----------------- Screw (9/64-40×6)-------------------- 1
ZSB11008
螺
丝----------------- Screw (11/64-40×5)------------------
-
2
3.CS-7500 针棒竖轴下轴机构 NEEDLE BAR UPRIGHT SHAFT LOWER SHAFT MECHANISM
Remarks
Name of Parts
7
GOLDEN WHEEL
