零件号码 零件名称 件数 备注 零件号码 零件名称 件数 备注
Parts No. Name of Parts
QTY Parts No. QTY Remarks
EP1182-0B 防油圈-------------
-
Retaining Ring----------------------------- 1 ZMG05026 螺丝--------------
-
Screw(M5-0.8×4)---------------
-
1
EP1187-0A
压棒弹簧----------
-
Spring---------------------------------------
-
1 ZMG05027
螺
丝--------------
-
Screw(M5-0.8×5)---------------
-
1
EP1191-0A
螺帽----------------
-
Nut------------------------------------------
-
1 ZMH05001
螺
丝--------------
-
Screw(M5-0.8×5)---------------
-
2
EP2495-0A
护架----------------
-
Finger Guard------------------------------- 1 ZMH06008
螺
丝--------------
-
Screw(M6-1.0×6)---------------
-
1
LN1083-0A
压棒滑
----------
-
Slide Block--------------------------------- 1 ZMJ04001
螺
丝--------------
-
Screw(M4-0.7×8)---------------
-
2
LN1180-0A
压棒----------------
-
Presser Bar---------------------------------
-
1 ZMJ04002
螺
丝--------------
-
Screw(M4-0.7×10)-------------- 1
LN1186-0A
压棒钳-------------
-
Connecting Bracket-----------------------
-
1 ZMJ05003
螺
丝--------------
-
Screw(M5-0.8×15)-------------- 1
LN1193-0A
滑块导轨----------
-
Presser Bar Guide-------------------------
-
1 ZMJ05011
螺
丝--------------
-
Screw(M5-0.8×8)---------------
-
1
LN1231-356A
压脚组件----------
-
Presser Foot Complete-------------------
-
1 ZMJ06008
螺
丝--------------
-
Screw(M6-1.0×12)-------------- 2
LN1314-0A
提升拉杆----------
-
Lifter Connecting Plate------------------- 1 ZML05005
螺
帽--------------
-
Nut(M5-0.8)---------------------
-
1
LN1315-0A
提升杆曲柄-------
-
Lifter Shaft Lever-------------------------
-
1
LN1318-0A
压棒提拉杆-------
-
Lifter Link---------------------------------- 1
LN1324-0A
提升轴-------------
-
Lifter Pin-----------------------------------
-
1
LN1325-0A
拉杆曲柄----------
-
Lifter Link Lever--------------------------
-
1
LN1328-0A
拉簧----------------
-
Return Spring------------------------------
-
1
LN2451-0A
压料调节螺丝棒-
-
Presser Spring Screw---------------------
-
1
LN2483-0A
提升杆-------------
-
Lifter Shaft---------------------------------
-
1
LN2484-0A
提升挡架----------
-
Lifter Lever Stopper----------------------
-
1
LN2485-0A
扭簧----------------
-
Spring---------------------------------------
-
1
LN2486-0A
销-------------------
-
Pin(5×20)----------------------------------- 1
LN4277-0A
挡圈----------------
-
Collar(12×20×10)-------------------------
-
1
RE000050
挡圈----------------
-
Retaining Ring----------------------------- 1
RE000070
E型挡圈-----------
-
Retaining Ring----------------------------- 1
WA059009
垫圈----------------
-
Washer-------------------------------------- 1
ZMB03020
螺丝----------------
-
Screw(M3-0.5×5)-------------------------
-
1
ZMB05020
螺丝----------------
-
Screw(M5-0.8×17.5)---------------------
-
1
ZMD04011
螺丝----------------
-
Screw(M4-0.7×5)-------------------------
-
1
ZMG05025
螺丝----------------
-
Screw(M5-0.8×5)-------------------------
-
1
9.　CSN-1400　压料机构　 PRESSER FOOT MECHANISM
Remarks
Name of Parts
19
GOLDEN WHEEL
